ANBEN / DURA-K FIRE BOARD

ANBEN DURA-K FIRE BOARD

Calcium silicate fire-protection board: material properties, nominal sizes, thicknesses and weights for the catalogue systems.

← Back to board systems
Catalogue cover illustration
Catalogue cover illustrationCatalogue: English pp. 1; Chinese p. 1.

Complete material properties

PropertyCatalogue value / optionReference
CompositionCalcium silicate; asbestos-freeISO 22262-1
Reaction to fireA1EN 13501-1
System fire resistanceUp to 240 min, according to the complete systemBS EN 1363-1 & -2; BS 476
Density (105°C / 24 h)970 kg/m³ ±10%EN 12467
AlkalinitypH 7–10Not stated
Length toleranceLevel 1EN 12467
Width toleranceLevel 1EN 12467
Thickness tolerance0.35 mmEN 12467
SquarenessLevel 1; 0.30 mm/mEN 12467
Thermal value*0.054 m²·K/WEN 12664
Modulus of elasticity4230 MPaEN 12467
Flexural strength8.1 MPaEN 12467
Warm-water resistanceRL = 0.84EN 12467, 7.3.5
Wet-dry cycling25 cycles; result not statedEN 12467, 7.3.6

The source calls the thermal value “conductivity” but uses a thermal-resistance unit. The value and unit are reproduced without reinterpretation; confirm the property, thickness and test conditions before design use. A1 is a material reaction-to-fire class; fire-resistance duration belongs to the complete system.

Board dimensions & weights

2400 × 1200 mm / 2440 × 1220 mm

ThicknessNominal mass per unit area
9 mm8.7 kg/m²
12 mm11.6 kg/m²
15 mm14.6 kg/m²
18 mm17.5 kg/m²
20 mm19.4 kg/m²
24 mm23.3 kg/m²

The solid-partition details use 32 mm board; its mass is not given in the general table. A1 is a material classification; fire-resistance duration belongs to the complete wall, ceiling or enclosure system.

System selection

E denotes integrity; EI denotes integrity and insulation. Ratings apply to the complete documented assembly. Confirm the board layers, steelwork, insulation, fixings, joints and supporting construction in the corresponding report.
