Acoustic fire-rated doors & windows

MINGAN / FIRE-RATED DOORS & WINDOWS

Acoustic fire-rated doors & windows

Fire-rated acoustic doors, windows and partitions address spaces requiring both fire separation and sound insulation. Options can be discussed around glazed, steel or timber openings and fixed glazed partitions.

CATALOGUE TECHNICAL INFORMATIONEI30 / EI60 / EI90 / EI120 / EI240

Fire-rated glazed, steel and timber doors, windows and fixed partitions with acoustic options.

Ratings refer to the respective documented configurations.

Acoustic door and window options

Product typeListed fire resistanceAcoustic value (dB)
Glazed doors / windowsEI6036 / 39 / 52 / 54
Glazed doors / windowsEI12041 / 44 / 48
Steel doorsEI12046
Steel doorsEI24050
Timber doorsEI6039
Timber doorsEI12040 / 42
Timber doorsEI24048

Each figure is a separate catalogue option. The table does not state the acoustic test method, so the values are not relabelled as STC or Rw. Confirm the matching tested construction.

Fixed acoustic fire-rated partition elevation and section

Fixed acoustic fire-rated partition elevation and section
Chinese product handbook 2025, p. 50.View full-size drawing ↗
•
Galvanised steel tubes and sheets
•
Stainless steel cladding
•
Glass and fire-resistant interlayers
•
Air cavity and PVB interlayer
•
Glazing setting blocks

Acoustic partition glass data

Thickness (mm)Listed fire resistanceAcoustic value (dB)Weight (kg/m²)
22E603043
42E1204568
66E6053110
71E6053130

On small screens, swipe the table horizontally to see every column.

The source table uses E60 and E120, while its general range lists EI ratings. The table notation is preserved without upgrading it to EI. Confirm classification, acoustic method and construction against the relevant reports.

Finish and application

Powder coating, fluorocarbon coating, brushed or mirror-polished stainless steel, aluminium panels and titanium-coloured finishes, depending on the system.

Applicable project types include hospitals, schools, offices and industrial buildings. Acoustic performance depends on the complete assembly, including perimeter seals, glazing and hardware.

Drawings are catalogue construction illustrations. Their dimensions and components describe the shown arrangement; project installation follows the approved system detail.

Typical applications

Fire boundaries in hospitals, schools, offices and industrial buildings where sound transmission between spaces or across the envelope needs to be controlled.

Options to discuss

First distinguish doors, fixed windows and partitions, then establish access, daylight and appearance needs. Acoustic performance must be supported for the complete assembly with its relevant seals, glazing and hardware.

Choosing the right system

STC, Rw and unqualified dB values are not interchangeable. Fire and acoustic results from different specimens cannot be combined into a performance promise for one assembly.

Information for your project

Fire classification and duration; acoustic metric and measurement method; door, window or partition form; layout and access; installation boundaries.
